Description
SmartSolar MPPT 100/30
Get maximum performance from your solar panels with advanced MPPT technology.
Why Choose This Product?
- 98% efficiency → more energy, more savings
- Smart charging → longer battery life
- heat resistant (-30°C to +60°C)
- Protection: Overheat, short circuit, reverse polarity
Ideal For
- Home solar systems
- Off-grid setups
- EV charging solutions
- Small businesses
Technical Specs
| Battery | 12/24V Auto |
| Charge Current | 30A |
| Solar Power | 440W / 880W |
| Max PV Voltage | 100V |
| Efficiency | 98% |
| Temperature | -30°C to +60°C |
Design
- Blue (RAL 5012)
- IP43 protection
- Weight: 1.3 kg
Limited stock available.
Feature highlights common to all models
- Ultra-fast Maximum Power Point Tracking (MPPT).
- Advanced Maximum Power Point Detection in case of partial shading conditions.
- Outstanding conversion efficiency.
- Natural convection cooling.
- Automatic battery voltage recognition.
- Flexible charge algorithm.
- Over temperature protection and power derating when temperature is high.
Sizing options:
- Suitable for a variety of battery voltages. Most models connect to 12, 24, and 48V batteries, some only
connect to 12 and 24V batteries, or only to 48V batteries. - Charge currents rating from 10A all the way up to 100A.
- Maximum PV array Voc voltages ranging from 75V up to 250V.
- Multiple chargers can be used in parallel, for large systems we recommend to use the models with a
VE.Can communication port.
PV terminal options:
- TR – one positive and one negative screw terminal.
- MC4 – 3 pairs of paralleled MC4 connectors.
Bluetooth options:
- SmartSolar models have Bluetooth.
- BlueSolar models do not have Bluetooth. They can be retrofitted to have Bluetooth by connecting the
VE.Direct Bluetooth Smart dongle. Advantage: the product is not Bluetooth accessible when the
dongle is not connected. Note that on the SmartSolar models, Bluetooth can be disabled.
Display options:
- VictronConnect Application. Connects via Bluetooth or via the VE.Direct – USB interface
- MPPT Control. Connects to all models via a VE.Direct cable
- SmartSolar Control Display. Plugs directly into the housing of the larger models
- GX device
- VRM website (GX monitoring device needed)
Communication ports: - VE.Direct – all models
- VE.Direct and VE.Can – limited models. VE.Can is especially suitable for systems with multiple solar
chargers. All units are simply “daisy chained” to each other with a single RJ45 cable between each unit
and also between the last unit in the chain and the a GX monitoring device.
Temperature sensor options:
- Internally (all models).
- Externally via the Smart Battery Sense (only SmartSolar models).
Load output options:
- Physical output – On the 10, 15 and 20A models.
- Virtual output – via VE.Direct TX digital output cable and the BatteryProtect or a solid-state relay.
Remotely enabling and disabling the charger:
- All larger units feature the Victron standard remote on/off terminals. All models that don’t feature an
onboard Remote on/off terminal can be remotely controlled by using the VE.Direct non inverting
remote on/off cable – ASS030550310. Note that this prohibits using the VE.Direct port for anything
else.
Firmware update options:
- Local updates via the VictronConnect Application (via Bluetooth or USB-VE.Direct interface)
- Remote updates via VRM website and a GX device
Optional accessories:
- VictronConnect Application (free download)
- Wire boxes, to cover and protect the terminals. See table on page 2 for wire box types
- Control and display panels: MPPT control or SmartSolar control)
- GX monitoring device (CCGX, Venus GX, Octo GX or Cerbo GX)
- Data cables: VE.Direct cable, RJ45 Cable (VE.Can models only), USB-VE.Direct interface
- External control cables: TX cable, non-inverting cable
- Bluetooth dongle (for non-smart models)
